Industrial Gigabit 90W PoE++ Media Converter 1G RJ45+1G SFP
Model:WXA-I01G-1SFP-P90
1×10/100/1000T RJ45 802.3bt 90W PoE
1×100/1000X SFP
48-57V
Original price was: $90.00.$74.00Current price is: $74.00.
WXA-I01G series hardened media converter is a dedicated industrial-grade networking device for copper-fiber signal conversion.
It supports 10/100/1000BASE-T ↔ 1000BASE-X bidirectional transmission, and the fiber port is backward compatible with 100M bandwidth to meet diverse network deployment needs.
- 1 x 10/100/1000BASE-T RJ45 Auto-MDI/MDI-X Ports
- 1×100/1000X SFP
- Supports Full/Half-duplex, Auto-negotiation
- IEEE 802.3az Energy Efficient Ethernet (EEE)
- Optional IEEE 802.3af/at/bt PoE Support
- Supports DIN-Rail & Wall-mount Installation
- IP40 Aluminum Case
- Environmentally hardened Operating Temperature: -40°C to 75°C (-40°F to 167°F)
| Ethernet | Ethernet Standards | IEEE802.3 10Base-T, IEEE802.3u 100Base-TX/FX, IEEE802.3ab 1000Base-T, IEEE802.3z 1000Base-X, IEEE 802.3az (EEE) |
| PoE Standards | IEEE802.3af/at/bt | |
| Forwarding Mechanism | Store-and-Forward | |
| Forwarding Rate | 14,880pps (10Mbps), 148,800pps (100Mbps), 1,488,000pps (1000Mbps) | |
| Packet Buffer Memory/Max Packet Length | 1 Mbit/9K Bytes | |
| Address Table Size | 2048K MAC Addresses | |
| Interface | Connector
Optical Port |
1x RJ45
1 x 1000Base-X SC |
| Electrical & Mechanical | Input Power | 48~57VDC, 4-pin terminal block |
| Output Power | 48VDC | |
| Power Consumption | 95W (Max.) | |
| LED Indicators | PWR (Power Status), L/A (Data LINK Status), POE (PoE Status), 100M/1000M (Fiber LINK Status) | |
| Dimensions (WxDxH) | 95 x 70 x 30 mm | |
| Weight | 0.25Kg | |
| Environmental | Operating Temperature | -40°C to 75°C (-40°F to 167°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) | |
| Relative Humidity | 5% to 95% non-condensing | |
| MTBF | > 200,000 hrs |
